Replay XD1080 Action Camera

Rotate, Tilt, Swivel, Clip, Mount, Etc.

Replay XD1080 can be mounted practically anywhere due to its small form-factor and all-round shape. There are two mounts included with each system to get you recording in no-time.HeimLock Mount (Swivel/Tilt): Features spherical adjustment with an eccentric cam-lock for a rock solid mount. Over 1,036,800 Mounting Positions with 360º lens rotation, 360º camera rotation, and 8º of tilt, not including the unlimited areas you can mount 1 of 4 included SnapTray VHB bases. Included are 2 Flat SnapTrays and 2 Curved SnapTrays with 3M® VHB adhesive to securely mount to smooth surfaces: metal, paint, powdercoat, LSE & HSE plastic. 3M® VHB adhesive ensures secure mounting and removal without harming your surface. LowBoy Mount (Fixed): Lowest profile mount, offers 360º lens rotation. Designed to be low and out-of-the-way. Compatible with our SnapTray VHB bases. HardCore (Billet): Optional billet-aluminum pro mounts are available for the most demanding action and motorsport applications. Tubular, Flat, Curved, Tripod, Universal, & Specialty mounts are available.

Live Action via HDMI

Replay XD1080 is the first to stream full 1080 HD through the built-in HDMI out connector. You can record and stream your video simultaneously or just stream your video straight to an external HD recorder.

Compatible with: Live streaming via HDMI microwave, WiFi, 4G Transmitters & HDMI In HD Recording Decks.

Finely Tuned Optics

Audio Times Two

Internal Audio:
Along with everything else, we spend a lot of time obsessing over audio. We’ve accumulated thousands of hours developing, engineering, and testing the right combination of acoustic materials and microphones to suppress windnoise yet still capture realistic audio.

External Audio*
For the extra critical audio situation we have built in an External Audio option to connect high quality Lav Mics,Ext. Audio sources, or other In-car Radio Communication through a standard 3.5mm Mini-jack adapter.

*External Audio Line-In available via Replay XD1080 HW Adapter. Available Soon

Many Modes. Easy to Use.

1080P@30fps, 960P@30fps, 720P@60fps, 720@30fps, Photo@1, 5, 10 & 15 sec, Internal Audio, External Audio, Rec, Stop, Play, Skip Forward, Skip Reverse, Clip File, Live Video Out. Wow. That’s a lot of modes. Don’t worry we made it easy. Set the Mode once and it sticks. There’s no need to count button presses or reset your settings each time you use the Replay XD1080.If you forgot what mode you were in or what they mean, just look inside the rear cover for a simple reminder.

Size Really Matters

Replay XD1080 was designed with size and weight in mind. HD cameras don’t need to be big and bulky to capture great video. Replay XD1080 utilizes the perfect blend of size, shape, and style.

Resilient

Replay XD1080 features a high-strength aerospace aluminum body – Mil-Spec hard-anodized for extreme durability to withstand the inherint demands of video-actionography. Weather-resistance is a must when dealing with action-cameras, so Replay XD1080 features a double o-ring sealed lens bezel, rear cap, and top push buttons to keep out those harsh elements.

How to - getting started with your 1080

Price

Display

External display option (available late 2011)
iPad with iOS4 or higher File Import Compatible
Android Compatible (Select Devices)

Removeable Storage

microSDHC (up to 32GB)
4GB micro SDHC Included

Ports

HDMI 1.3a Out
-Live HD Video Streaming
-HD Video & Photo Playback, Thumbnail Display, Play/Stop, Skip Forward/Reverse, Menu On/Off
-External Mic/Audio Line-In
8 Pin Mini-USB 2.0
-Charge and Sync
-Timecode Out
microSDHC slot
-up to 32 GB

Power

AC Power 100~240 V, 50~60 Hz
Rechargeable Internal Li-ion Battery 3.7 V, 750 mAh*
up to 122 Minute Record Time*

Housing

Durable Aluminum Housing
-Type-1 Black Anodized
-Round for 360º Mounting Rotation
-Impact Resistant
Black with Laser Etched Logos
-Easy Alignment
-Discrete Placement
O-ring Sealed
-Front and Rear Bezel
-Exterior Buttons
Weather Resistant

Size

28 mm Dia. x 93 mm Length, 27 mm Mounting Dia.
1.1 in Dia. x 3.6 in Length, 1.063 in Mounting Dia.
96.2 mm with Lanyard Cap
3.78 in with Lanyard Cap

Weight

85 grams (including battery & microSDHC)
3 ounces

Control

On Top: Power "On/Off" & Select "Record, Stop, Playback, Clip File" Buttons with Vibration Feedback
On the Back: Mode "1080P, 960P, 720P, Photo, Heads-up On/Off, FPS "60 fps, 30 fps, 3, 5, 15, 30 Sec.
Audio: Internal Mic & External Mic Selection

Photo Mode

5 MP JPEG Photo 2592 x 1944
1 Photo per 3, 5, 15, 30 sec

Video Settings

H.264 Codec, Quicktime .mov file type
Live HD Playback, Live HD View, Live HD Streaming
Bitrate Adjustment: High, Medium, Low
Exposure Control EV Adjustment
Auto Exposure Metering: Center, Average, Spot
Automatic White Balance with Adjustment
Contrast Adjustment
Sharpness Adjustment
Saturation Adjustment
Microphone Audio Gain Control
Date and Time Adjustment
Heads-up Display via HDMI Port On/Off

Video Resolution

5 MP (2592 x 1944) CMOS Sensor
1080P 1920 x 1080, 30 fps, Bitrate M(bit/s) = up to 15M
960P 1280 x 960, 30 fps, Bitrate M(bit/s) = up to 15M
720P 1280 x 720, 60 fps, Bitrate M(bit/s) = up to 15M
720P 1280 x 720, 30 fps, Bitrate M(bit/s) = up to 15M
HDMI HD Video Streaming, Real-time HD H.264.
NTSC 30/60 and PAL 25/50 option

Optics

F3.1±5% Wide Angle
110.5 Degrees @ 1080P
135 Degrees @ 960P, 720P
135 Degrees @ Photo
1.3V/lux-sec Light Sensitivity

Lens Cover

Replaceable Aluminum Bezel and Lens Cover

Audio

Internal Omnidirectional Microphone
AAC and AC3 2-channel
48K, 16-bit, Auto Gain
External Mic-in 0.707 Vrms

Power Supply

5V +/- 0.5V / 2A

System Requirements:

PC Video Playback

Windows

Intel® Core Duo® or higher
Windows® XP with Service Pack 3, Windows Vista, Windows 7
1920 x 1080 screen resolution
USB 2.0 Port, Mouse

Macintosh

Intel® Core Duo® or higher
Mac OS X v.10.5, 10.6, 10.7
USB 2.0 Port, Mouse

* Specifications are subject to change prior to shipping.
